A100 Aluminum Vertical Mount Drapery Track
Aluminum hand-drawn track with vertical flange is normally affixed directly to wall using standard fasteners. This track can also be recessed, depending on application.
Description:
Extruded 6063-T5 aluminum track is etched, anodized, and siliconized. Clear satin finish is rust proof and chip proof. Track comes in 16 ft standard lengths, but can be cut to length for an additional charge.
Installation:
Track should be mounted to wood using standard fasteners, or to plaster using #6, #8, or #10 screws, positioned 4" apart. Installation should allow 1/4" clearance between track end and end wall. Install carriers, gliders, or sew-on tabs at 3" on center. Draperies should be attached starting at the center, removing or adding carriers as needed at the notches on either end of the track. Complete installation using M-114 or M-115 end stops.
Dimensions:
Channel Height: 0.195”
Channel Width: 0.245”
Total Height: 0.655"
Total Width" 0.325”
A101 Aluminum Horizontal Mount Drapery Track
Aluminum hand-drawn track with horizontal flange is normally affixed directly to wall using standard fasteners. This track can also be recessed, depending on application.
Description:
Extruded 6063-T5 aluminum track is etched, anodized, and siliconized. Clear satin finish is rust proof and chip proof. Track comes in 16 ft standard lengths, but can be cut to length for an additional charge.
Installation:
Track should be mounted to wood using standard fasteners, or to plaster using #6, #8, or #10 screws, positioned 4" apart. Installation should allow 1/4" clearance between track end and end wall. Install carriers, gliders, or sew-on tabs at 3" on center. Draperies should be attached starting at the center, removing or adding carriers as needed at the notches on either end of the track. Complete installation using M-114 or M-115 end stops.
Dimensions:
Channel Height: 0.225”
Channel Width: 0.248”
Total Height: 0.270"
Total Width" 0.658”
A102 Aluminum Surface Mount Drapery Track
Aluminum hand-drawn track is normally affixed directly to ceiling surface using screws or M-123 mounting clips. May also be side-mounted using M-3512 gliders.
Description:
Extruded 6063-T5 aluminum track is etched, anodized, and siliconized. Clear satin finish is rust proof and chip proof. Track comes in 16 ft standard lengths, but can be cut to length for an additional charge.
Installation:
Track should be mounted to wood using standard fasteners, or to plaster using #6, #8, or #10 screws, positioned 4" apart. Installation should allow 1/4" clearance between track end and end wall. Install carriers, gliders, or sew-on tabs at 3" on center. Draperies should be attached starting at the center, removing or adding carriers as needed at the notches on either end of the track. Complete installation using M-114 or M-115 end stops.
Dimensions:
Channel Height: 0.159”
Channel Width: 0.255”
Total Height: 0.288"
Total Width" 0.477”
A104 Aluminum Architectural Drapery Track
Aluminum hand-drawn track is normally affixed directly to ceiling surface using standard fasteners. Track can be curved to 8"-12" radius.
Description:
Extruded 6063-T5 aluminum track is etched, anodized, and siliconized. Clear satin finish is rust proof and chip proof. Track comes in 14 ft standard lengths, but can be cut to length for an additional charge. Comparable to Kirsch™ 9046 track.
Installation:
Track should be mounted to wood using standard fasteners, or to plaster using #6, #8, or #10 screws, positioned 4" apart. Track installation should allow 1/2" clearance between track end and end wall. Install carriers at 3" on center and attach draperies starting at the center, removing or adding carriers as needed at either end of the track.
Dimensions:
Channel Height: 0..400”
Channel Width: 0.500”
Total Height: 0.500"
Total Width" 0.620”
A105 Aluminum Drapery Track, i-beam
Aluminum, hand drawn track comes in 8 ft lengths. Track can be mounted to the ceiling using M-122 brackets or to the wall using M-119 brackets.
Description:
Extruded 6063-T5 aluminum track is anodized, with a clear satin finish that is rust proof and chip proof. Track comes in 8 ft standard lengths, but can be cut to length for an additional charge.
Installation:
Track can be mounted to the ceiling using M-122 ceiling brackets or to the wall using M-119 I-beam brackets.
Dimensions:
Height: 0.650"
Width: 0.250"
V100 Vinyl Vertical Mount Drapery Track
Vinyl, hand-drawn track with vertical flange is normally affixed directly to wall using standard fasteners, This track can also be recessed, depending on the application.
Description:
Extruded PVC track is high gloss, durable, and able to withstand nailing, stapling, and pneumatic die cutting. Track comes in standard 12 ft lengths but can be cut to length for an additional charge.
Installation:
Track should be mounted to wood using standard fasteners, or to plaster using #6, #8, or #10 screws, positioned 4" apart. Installation should allow 1/4" clearance between track end and end wall. Install carriers, gliders, or sew-on tabs at 3" on center. Draperies should be attached starting at the center, removing or adding carriers as needed at the notches on either end of the track. Complete installation using M-114 or M-115 end stops.
Dimensions:
Height: 0.700"
Width: 0.340"
V101 Vinyl Horizontal Mount Drapery Track
Vinyl hand-drawn track with horizontal flange is normally affixed directly to wall using standard fasteners. This track can also be recessed, depending on application.
Description:
Extruded PVC track is high gloss, durable, and able to withstand nailing, stapling, and pneumatic die cutting. Track comes in standard 12 ft lengths but can be cut to length for an additional charge.
Installation:
Track should be mounted to wood using standard fasteners, or to plaster using #6, #8, or #10 screws, positioned 4" apart. Installation should allow 1/4" clearance between track end and end wall. Install carriers, gliders, or sew-on tabs at 3" on center. Draperies should be attached starting at the center, removing or adding carriers as needed at the notches on either end of the track. Complete installation using M-114 or M-115 end stops.
V102 Vinyl Surface Mount Drapery Track
Vinyl hand-drawn track is normally affixed directly to ceiling surface using screws or M-123 mounting clips.
Description:
Extruded PVC track is high gloss, durable, and able to withstand nailing, stapling, and pneumatic die cutting. Track comes in standard 12 ft lengths but can be cut to length for an additional charge.
Installation:
Track should be mounted to wood using standard fasteners, or to plaster using #6, #8, or #10 screws, positioned 4" apart. Installation should allow 1/4" clearance between track end and end wall. Install carriers, gliders, or sew-on tabs at 3" on center. Draperies should be attached starting at the center, removing or adding carriers as needed at the notches on either end of the track. Complete installation using M-114 or M-115 end stops.
Plastic eyelet carrier compatible with our smaller gauge curtain tracks
Plastic eyelet carrier with stainless steel hook attached. Compatible with our smaller gauge curtain tracks.
Plastic carrier is designed so that the tab portion can be sewn into curtains, with the head fitting any one of our six smaller-gauged tracks.
Available in black or white.
Plastic carrier is designed so that the tab portion can be sewn into curtains, with the head fitting our larger A-104 curtain track.
Tape is made of M-112 Sew-On Tabs heat-sealed to ¾” nylon ribbon at standard 4” intervals.
Available in black or white.
Nylon ribbon available in two weaves - grosgrain or herringbone.
Rectangular steel end stop with screw, compatible with our smaller gauge track.
Plastic end stop with screw. Loop accepts most curtain hooks. Compatible with our smaller gauge tracks.
Plastic end stop with tapered ribs to ensure secure fit. Compatible with our A-104 track.
Available in black only.
M-117 I-Beam Carrier Write a description for this list item and include information that will interest site visitors. For example, you may want to describe a team member's experience, what makes a product special, or a unique service that you offer.
M-118 Cafe Ring
M-119 I-Beam Wall Bracket
M-120 I-Beam End Stop
M-121 Wall Plug
M-122 Ceiling I-Beam Bracket
M-123 Mounting Clip
M-210 Button Carrier
M-211 Button Carrier w/Hook
M-226 Snap-on Carrier
M-227 Snap-on Tape
M-228 Single Snap Carrier
M-230 Clip-On Carrier
M-232-L Large Boat Hook
M-232-S Small Boat Hook
M-234 Plastic Hook
M-301 T-Glide
M-301-2 T-Glide w/2" Elastic
M-301-4 T-Glide w/4" Elastic
M-3512 Glider
